Royale
Aluminium Channel with Glass Bracket
The Royale design is a luxurious and elegant option for your railing needs. It
features an aluminium channel that is either side-mounted or top-mounted to
the floor creating a sleek and seamless look. The aluminium channel is
made of high-quality aluminium anodized and powder-coated to resist
corrosion and rust. The aluminium channel can hold tempered glass panels
or laminated glass panels as infill, creating a transparent and modern
appearance
This mounting option consists of an aluminium channel that is top-mounted to the floor or
the wall, creating a stylish and refined appearance. The aluminium channel is attached to
the floor or the wall using visible fasteners, creating a contrast and texture. This option is
ideal for those who want a high-end and sturdy railing system that can add a touch of class
to any space.
| TECHNICAL DATA | TYPE/SHAPE | STANDARD SPACING / SIZE IN mm (Inch) |
|---|---|---|
| Shoe | Top/Fascia | Continuous |
| Infill option | Glass with Brackets | 12.76 to 27 mm (1/2" to 1-1/16") laminated glass |
| Top Rail / Hand Rail | Round or Square Tube | Dia. 48.3 mm (1-29/32") / 38.1 mm (1-1/2") - Standard Sq. 40x40 mm (1-9/16" X 1-9/16") - Standard |
| Top Rail / Hand Rail (U-tube) | Round or Square U Tube | Dia. 42.4 mm (1-21/32") - Standard Sq. 40x40 mm (1-9/16" X 1-9/16") - Standard |
| Top Rail / Hand Rail (U-Cap) | Top U-Cap | 25 to 38 mm (1"to 1-1/2") high |
Additional information
| Infill Option | Glass |
|---|---|
| Model Name | Royale |
| Mounting Options | Top, Side |
| Top Rail Attachments | Round Tube, Round U Cap, Square Tube, Square U Cap |
